Layer 3 wires, one for 5 hours, let the corners be corners, let the grooves be grooves
Core technology: adaptive layering, the most subdivided layer 3 wires
Printing speed: 500 layers/hour
Operating environment: support office environment, no compartment required
Printing materials: hard materials, elastic, flexible materials
Software support: Polydevs data processing software
Friendly interaction: easy refueling, simple maintenance
Recommended Applications:
Mass production of wooden molds
Rapid tooling
Research and development of samples
Try-on of new products
|
Build Volume |
252 x 140 x 240 mm 9.9 × 5.5 × 9.4 in |
|
Accuracy |
Dimension <100 mm: ±0.1 mm Dimension ≥100 mm: ±0.1% x Dimension |
|
Layer Thickness |
Within 0.03 mm |
|
Laser |
Imported 4K machine |
|
Material |
Hard,soft and elastic materials |
|
Controlling Software |
UnionTech™ RSCON |
|
Data Preparation Software |
Polydevs |
|
Operation System |
Windows 10 |
|
Network Type and Protocol |
WiFi, Ethernet Using MQTT, HTTP, TCP |
|
Electrical Requirements |
200-240 VAC, 50/60 Hz, |
|
Rated Power |
3.8 kVA |
|
Systems Control |
Closed-loop |
|
Temperature Range |
72–79 °F (22–26 °C) |
|
Maximum Change Rate |
1 °C/hour |
|
Relative Humidity |
< 40% |
|
Machine Size (W x D x H) |
600 x 510 x 1440 mm |
|
Processing and Finishing |
Post-Curing Unit (optional) |
|
Warranty |
12 Months |
Consult with your sales representative for confirmation of current offering.
