Pilot450 Industrial SLA 3D Printer

  • Industrial stereolithography 3D printing technology

  • Practical build capacity of 450 × 450 × 400 mm

  • Industry-leading print quality, speed and precision

  • 3D printing software for file preparation and production

  • Compatible with a variety of 3D printing materials

Pilot450

Pilot450 Technical Data

Build Volume450 × 450 × 400 mm 17.7 × 17.7 × 15.7 in
Accuracy

Dimension <100 mm: ±0.1 mm

Dimension ≥100 mm: ±0.1% x Dimension

Layer Thickness0.05-0.25 mm
Laser

355 nm, solid-state frequency tripled

Nd: YVO₄

Beam Focus

Dynamic & Variable
Beam Size0.08-0.12 mm
Material

Compatible with commercial available resins for 355 nm stereolithography

Scanning Speed6-10 m/s
Controlling SoftwareUnionTech™ RSCON
Data Preparation SoftwarePolydevs
Operation SystemWindows 10
Input File Format.usp
Network Type and Protocol

WiFi, Ethernet

Using MQTT, HTTP, TCP

Electrical Requirements200-240 VAC, 50/60 Hz
Rated Power3.0 kVA
Systems ControlClosed-loop
Temperature Range72–79 °F (22–26 °C)
Maximum Change Rate1 °C/hour
Relative Humidity< 40%
Machine Size (W x D x H)1310 × 1290 × 2135 mm
Machine Weight945 kg
Initial Resin Weight160 kg
Resin VatManually Replacing
Processing and FinishingPost-Curing Unit (optional)
Warranty12 Months
Regulatory ConformityCE / UKCA
